Style 9800 High Temp Gasketing
Style 9800 gasket is a high temperature gasketing composed of carbon fibers with an SBR binder. This high performance material maintains its seal during pressure and temperature fluctuations, reducing leakage rates and maintenance time.
- Description
- Характеристики
Description
- Excels in the harshest conditions — intense heat, high pressure, saturated steam* and hot oils
- Laboratory tested for fire safety
- Maintains effective seal during pressure and temperature fluctuations
- Superior torque retention lowers leakage rates and reduces maintenance time
- Convenient
- Flexible material is easy to handle and cut
- Sheet sizes from 60” x 60” (1.5m x 1.5m) up to 150” x 150” (3.8 m x 3.8 m) minimize waste and inventory costs
*Minimum recommended assembly stress = 4,800psi. Preferred assembly stress = 6,000 — 10,000psi. Gasket thickness of 1/16” strongly preferred. Retorque the bolts/studs prior to pressurizing the assembly. For saturated steam above 150 psig or superheated steam, consult Garlock Engineering.
- Available in sheet or cut gasket form
- Min. Temperature: -100°F / -73°C
- Max. Temperature: 900°F / 482°C
- Continuous Max: 650°F / 343°C
- Max. Pressure: 2000 PSI / 138 bar
- Maximum PxT 1/16: 700,000 (°F x PSIG) / 25,000 (°C x bar)
- Maximum PxT 1/8: 350,000 (°F x PSIG) / 12,000 (°C x bar)
APPLICATIONS
- Saturated steam*
- Water
- Inert gases
*Minimum recommended assembly stress = 4,800psi. Preferred assembly stress = 6,000 — 10,000psi. Gasket thickness of 1/16” strongly preferred. Retorque the bolts/studs prior to pressurizing the assembly. For saturated steam above 150 psig or superheated steam, consult Garlock Engineering.
